2.5吨柴油叉车 Topone TL930 2ton Mini Front Wheel Loader
2.5吨柴油叉车 Topone TL930 2ton Mini Front Wheel Loader
- Topone
- Qingzhou City
- 15 days
- 100units / month
Rated load: 2000KG , Bucket: 1.0CBM , Engine: 76KW/100HP
1. Euro V engine & Cummins EPA4 for option;
2. Electric Joystick, LCD Dashboard, Reversing Image，Weighing system, Quick Hitch, for option
3. EVarious tread patterns and sizes of tires for different working .
Model | CPCD25 |
Dimensions | |
Overall Length(Without fork) | 2595mm |
Overall Width | 1160mm |
Overall Height | 2220mm |
Min. Lifting Height | 3000mm |
Fork Length | 1070mm |
Fork Width | 122mm |
Lifting Height | 4m 4.5m 5m 6m (option) |
Freedom lift height | 130mm |
Max.gradeability | 20% |
Min ground clearance | 115mm |
Weight | |
Rated Load | 2.5 TON |
Operating Weight | 3510KG |
Engine | |
Engine brand | Quanchai/Xinchai |
Rated power | 39kw |
Gear shift | |
Type | F2/R2 |
Tire | |
Front tire size | 7.00-12 |
Rear tire size | 6.00-9 |
Mountain Raise and products obtained international agency certification
MOUNTAIN RAISE has passed various corporate and product certifications in order to meet the quality requirements of different countries during its twenty years of development. It not only meets the requirements of China, but also meets the international requirements, such as global ISO, SGS, TUV, ROPS&FPOS, etc. CE certification that meets European quality standards, engine certification that meet...more
MOUNTAIN RAISE has passed various corporate and product certifications in order to meet the quality requirements of different countries during its twenty years of development. It not only meets the requirements of China, but also meets the international requirements, such as global ISO, SGS, TUV, ROPS&FPOS, etc. CE certification that meets European quality standards, engine certification that meet...more
